| Model |
JS – 965 – DU03 |
| Camera Specification |
| Image Sensor |
1 / 2.8 ” CMOS IMX307 |
| Signal System |
PAL / NTSC |
| Image Resolution |
2MP |
| Picture Pixels |
1920 ( H ) * 1080 ( V ) |
| Video Frame Rate |
1080p @ 25fps or 30fps |
| Video Output |
AHD ( TVI is optional ) |
| Transmission Distance |
More than 500m via 75-3 coaxial cable |
| Minimum Illumination |
Color : 0.001Lux , B / WW : 0.0001 Lux , 0Lux ( IR ON ) |
| Lens |
2.1mm 2MP IR board lens ( Indside – view ) , 2.8mm 2MP board lens ( Front – view ) |
| Sync System |
Internal Synchronization |
| Electronic Shutter |
PAL : 1/25 -1 / 50,000 Sec , NTSC : 1/30 -1 / 60,000 Sec |
| S / N Ratio |
More than 50dB |
| Day and night |
Indoor camera : Auto ( ICR ) / Color / BWV , Front camera : Color |
| Infrared LED |
14mil * $ 5 * 4pcs LEDS ( Inside – view ) |
| IR Distance |
2-3m ( Inside – view ) |
| Audio |
Built – in microphone for inside – view camera |
| WDR |
D – WDR |
| Noise Reduction |
3D NR |
| White Balance |
Auto / Manual |
| Gain Control |
Auto |
| General |
| Operation Temperature |
-20 ° C- + 70 ° C / Less than 95 % RH ( No condensation ) |
| Power Supply |
DC12V +/- 20 % |
| Cable |
3m shielded power & video cable with Aviation connector |
| Housing |
Black color plastic case , Bracket with 3M glue |
| Size |
109 * 44.5 * 60.5mm |
