Description
- Working voltage: DC12-36V
- TX consumption: 200ma/250ma max
- RX consumption: 200ma
- RF band width: 12 Mbps
- Modulation: QPSK/16QAM
- Tx Channel: 1 channels
- Working range: 500 meter
- Hopping rate: 1200/S
- Power on time: 2S
- Latency: 100ms Max
- Video codec: H.264
- T/R Frequency: 2400-2483.5Mhz
- Output power: 20dB
- Receiving sensitivity: -86dBm@ QPSK
- TX Video in signal format: AHD/TVI/CVI/CVBS Auto detection @1080P/720P/480P
- RX Video output signal format: AHD/TVI/CVI/CVBS Auto detection @720P
- Video Output impedance: 75Ω, Typ.
- Video Output Level: 1Vp-p, Typ.
- Audio Output impedance: 200KΩ, Typ.
- Audio Output Level: 5mv~0.2Vp-p, Typ.
- S/N(340Hz ~ 3.4kHz): 63dB, Min
- THD: 5 %, Max
- Waterproof: IP69K
- Connector: 4-pin plug
- Housing material: Aluminum Diecasting
- Current consumption: 200mA/12V
- Operating temperature: -20°C~80°C
